Single Flute Straight Plunge Solid Carbide CNC Bit

IMCNC

Single Flute Straight Plunge Solid Carbide CNC Bit

$20.00 USD
Unit price does not include freight, import tax, VAT., and duty. Check the H.S. Code with local customs and estimate the tax and duty rate. Only purchase if you accept the cost.
H.S. CODE
Quantity:

  • Ensure you are familiar with our Shipping and Returns/Refunds policies prior to purchasing.
4100G040         1 mm Single Flute Straight Plunge Solid Carbide CNC Bit

Features:

  • This particular bits is specially design for making plastic puzzle and cutting plastic.
  • The spiral solid carbide bit is designed to reduce tool marks which is commonly appear when carving with plastic.
  • Spiral design for fast and clean chip removal. The sharp cutting edge provides a smooth cutting experience.
  • Recommended pass depth at 0.5 mm or less.
  • Made from Solid Tungsten Carbide providing longer cutting life. State-of-the-art cutter geometries designed for better chip evacuation.
  • 4 mm tool shank fits perfectly on IMCNC engraver model.

Engraving Materials:

Plastics(ABS, Acrylic), Wood, MDF, Rubber, Leather, Foam, Styrofoam, Epoxy, etc.

Specification:

Bits Comparison



Item Number

4100G040

Diameter (d)

1 mm

Shank Dia. (D)

4 mm

Flute Length (H)

4 mm

Overall Length (L)

50 mm

Flute Number

1

Engraving Materials

It is mainly used for shallow carving or layered carving. It is necessary to avoid engraving too deeply in a single pass since the flute length is quite short.






Application:
